Heavy-Duty Label Printers: XLP 604, XLP 605, XLP 606

Features fast printing, auto ribbon-save & razor sharp print quality. If your criteria are speed and flawless print quality, then an XLP 60x barcode label printer is the perfect answer.

Heavy-duty, high-performance industrial label printers for barcode, text & graphics

The XLP 60x Series pack a punch: They are significantly faster than their competitors and are extremely economical and easy to use

Irrespective of whether you require barcodes, tags or production labels, at 300 dpi, the high print resolution guarantees unbeatable printed results, permanently

This is thanks to their high-performance processor

With their wide range of built-in fonts, extensive linear barcode and 2-Dimensional code library, they also reproduce graphical images with flair

In addition, they have the ability to rotate scalable fonts virtually without restriction, so there’s very little they can’t do!

Features

  • No Waiting - thanks to it’s multi-tasking operating system, the high speed CPU transfers your data almost instantaneously and delivers top-class results at up to 400 mm/s at a resolution of 300 dpi
  • Trust in the Dot Check - a tried and tested verification package (the standard dot check function and/or the optional online verifier) ensures reliable print results even with complex applications
  • Practical and Flexible - technology can be this simple: for example, the quick change function
  • Quick-Changes - the print head can be changed quickly and efficiently without the need for extra tools
  • Ribbon-Saving Mechanism - from as little as 6 mm of print-free space, the intelligent ribbon-saving mechanism significantly reduces material consumption and can make significant cost savings
  • Extraordinarily Economical - the XLP 60x printer series allows you to draw on unlimited resources
  • Ribbon capacity - up to 600 metres makes immediate savings and cuts set-up times dramatically
  • Printer Options - you can’t beat the modular concept:
    • A range of removable accessories such as cutters, rewinders and dispensers makes your work easier, supports all kinds of applications and provides the perfect finish to your printing processes

Technical Specification

Print width (up to)

106mm for XLP 604
127mm for XLP 605
160mm for XLP 606
213mm for XLP 64-08
Material width (up to)

113mm for XLP 604
154mm for XLP 605
185mm for XLP 606
254mm for XLP 64-08
Print Technology

Thermal direct and thermal transfer printer
Print Head

Intelligent, high-res near-edge print head with integral temperature control
Resolution

12 dots/mm (300) dpi
quick-change print head module
Print Speed

50-400 mm/s depending on label and ribbon combination
Print Media

Self-adhesive, card and synthetic materials suitable for direct thermal and thermal transfer printing up to 240 g/m2
Ribbon Capacity

Rolls up to 600m in length
Ribbon-Saving Mechanisms

Yes: Automatic head-lift
Emulation

Avery, Novexx EasyPlug, Zebra ZPL-II, Line printer, Hex dump
Machine material

Metal casing
